Front Range pavement gets worked on from three directions at once

Three layers, and only one of them is visible

Asphalt is not poured, it is not a slab, and it does not carry load the way concrete does. It is the top layer of a flexible structure, and the structure only works when each part is doing its own job.

Native ground sits at the bottom. It receives every load the property ever takes, and it sets the ceiling on what anything above it can achieve. Along this stretch of the Front Range it is frequently clay, and clay is not a stable foundation — it is a material whose volume depends on how wet it is.

Compacted stone sits above it. Its function is to take the concentrated pressure under a wheel and spread it out over a much larger footprint of ground before that ground ever feels it. Depth and compaction here are what determine the load a lot can take for how long. Nobody sees this layer and it is the one that decides everything.

The asphalt itself is a wearing course. It gives a smooth, sealed, durable driving surface, adds some capacity of its own, and above all it is the roof over the structure — the thing keeping water out of the two layers that matter.

Hold that picture and the trade becomes legible. Damage that begins on top and travels down can be treated on top. Damage that begins underneath and travels up cannot be treated on top at all, whatever is applied and however well it is applied.

Nearly all wasted pavement money in this metro sits in that gap. Buying a coating or a resurfacing for a lot whose stone and ground have already given way is not a bad purchase because the work is bad; it is a bad purchase because the money is being spent on the roof of a building whose foundation is the problem.

What the winter does, and what the summer does

Maintenance advice written for a temperate climate does not survive here. Two seasons attack the pavement in opposite ways, and a third mechanism runs underneath both of them all year.

Winter: water, leverage and steel

Every crack in a lot is a container. Rain and snowmelt fill it, the temperature drops, the contents expand, and the crack is levered a fraction wider than it was. Warm up, refill, repeat. Colorado delivers an unusual number of those cycles, including stretches where a lot freezes overnight and is thawed again by late morning.

No single cycle matters. The compounding does, because a wider opening admits more water and therefore does more work next time. This is the arithmetic behind the strongest maintenance recommendation anyone can make on this side of the country: close the cracks, and close them going into the season rather than coming out of it. Sealant placed in August buys a whole winter. The same sealant in April has already lost one.

Snow clearing adds a mechanical layer on top. A blade dragged across a lot removes markings directly and lifts material off any surface that has begun to lose its aggregate. The chemistry used alongside it sits in solution on the surface and works on paint and binder together. Both are necessary; neither is free.

Summer: sun at altitude, and a softer surface

The material holding aggregate in place is a petroleum binder, and sunlight breaks it down. At this elevation there is more ultraviolet energy arriving per square foot than the same pavement would receive nearer sea level, so the process runs faster than the textbooks assume. Lots here turn gray early, then begin shedding stone, then turn rough underfoot.

Heat does something separate. A dark surface in full summer sun reaches temperatures at which asphalt behaves plastically rather than elastically, and that is precisely when a loaded vehicle turning slowly can push it into ridges or press it into troughs. Deformation that shows up in July and August is this, and it does not recover in September.

All year: ground that changes size

Expansive clay takes on water and grows; it dries out and shrinks back. The movement is uneven across a property because moisture is uneven across a property — stable under the middle of a large lot, active at the edges, near planting beds, beneath a downspout outlet and anywhere runoff collects.

Pavement sitting on that records the movement faithfully, which is why cracking here often traces water rather than tires. It also means that irrigation controllers and roof drainage are pavement decisions on this ground, even though nobody manages them as such.

And a window that closes early

Hot mix has to be laid and rolled while it is still hot enough to compact, which depends on air temperature, ground temperature, wind and how thick the lift is. The practical season along the Front Range starts later and ends sooner than a national calendar suggests, and it is tighter again on the higher ground toward the foothills.

The consequence is a scheduling one with a cost attached. A structural defect left open across a winter is not paused; it spends five months admitting water and cycling. What needed a repair in September needs a larger repair in April, and the difference is measurable. Assessment and approval belong in the cold months so that the work is booked into the front of the season rather than chasing the back of it.

Request a callback

Send the address and what the surface is doing. We will call you back.

What we do

What the damage is telling you

Pavement fails in a handful of recognizable ways, and each one names its own cause. Matching the two is the diagnosis; everything after that is execution.

A web of connected cracks in the wheel tracks

When cracking links up into a network of small plates, concentrated where vehicles run or turn, the ground and stone below have stopped supporting the load. The surface is bending under every axle and fracturing because it was never designed to bend that far.

Nothing applied to the top of that changes it. Sealant will not hold in it, and a new layer placed over it will show the same network again within a few seasons because the movement underneath has not stopped. The affected footprint has to come out, the stone below has to be dealt with, and the area has to be rebuilt for the loads it actually receives. That is why a modest patch of this can outprice a large area of cosmetic work, and why any proposal offering to seal it has either misread it or is quoting something cheaper than the problem.

Holes that come back

A hole is usually that same network, one stage further on, with pieces now missing — helped along by water sitting in it and freezing. The interesting question is not what to put in it. It is why the failure landed in that specific spot and not three feet away.

When the same location opens up again after being filled, the lot is telling you plainly that either the support underneath is gone or water is arriving and never leaving. Refilling it is a recurring charge, not a repair. A cold-weather fill to close a hazard in February is entirely legitimate; treating that fill as the answer is not.

Single lines, running straight

Individual cracks that run in a line — along the direction of travel, across it, or down an old paving joint — usually begin in the surface rather than below it. Temperature movement, an aging binder and the joints from the original placement account for most of them.

These are the ones worth sealing, and in this climate sealing them is close to the best value available on any maintenance schedule. Left open through a Colorado winter they widen every few days, and once they are wide enough to move water into the stone below, a cosmetic defect has quietly become a structural one.

Gray, gritty, shedding stone

A surface that has gone pale and rough has lost binder to sunlight, and once enough of it is gone the aggregate starts coming loose. Underfoot it feels like coarse sandpaper; swept, it produces a pile of stone that used to be the lot.

Caught early, while the surface is still whole, this is the one condition a protective coating genuinely addresses. Caught late, after significant aggregate is gone, there is no longer an intact surface to protect and the honest answer is a new wearing course rather than a treatment over a disintegrating one.

Troughs and ridges where vehicles work

Channels pressed into the wheel tracks, or material shouldered up alongside where traffic brakes and turns, mean the pavement is being moved rather than broken. Either the material and depth were never specified for what is driving on them, or the layers beneath are still settling under the load.

A trough is also a basin, so it starts collecting water and adding the winter mechanism to the summer one. Where this appears beside a trash enclosure, at a dock or on a delivery route, the vehicles are the explanation, and replacing what is there with the same thing schedules the next occurrence.

Water that is still there an hour later

The most consequential defect on the property and the one least likely to appear on a proposal. Water that does not drain works into joints, softens the layers beneath, feeds the clay under those, and then freezes and levers everything apart.

A lot that ponds does not have a defect; it has a generator of defects, and it will keep producing them until the grade or the inlets are corrected. Snow storage extends the same exposure across days rather than hours, which makes where a plow operator piles snow a genuine pavement decision rather than a housekeeping one.

The order that saves money

Very little asphalt spending is wasted on poor workmanship. Most of it is wasted on competent work bought in the wrong order.

1. Water first. Anywhere it stands, anywhere it enters and does not leave, and anywhere a downspout or an irrigation zone is feeding the ground under the pavement. Nothing bought before this holds its value, and on clay the water is also controlling what the ground does.
2. Then the structure. The networked areas and the layers beneath them. This is the expensive category, it grows on its own, and it grows faster across a winter than across a summer.
3. Then close the openings. With the structure sound, sealing the remaining cracks is inexpensive and buys real years. Do it before the freeze season, not after.
4. Then the surface, if it has earned it. A new wearing course, milled in or laid over, decided by what is underneath and by whether the elevation is allowed to rise.
5. Then protection, if there is something to protect. A coating belongs on an intact surface, at intervals set by condition rather than by a contract renewal date.
6. Markings last, always. Paint is applied to a finished surface and to nothing else.

Any scope that leads with a coating on a lot showing structural damage has put the cheap item first. The two questions that expose it: was anything below the surface examined, and what is the plan for the water?

One property, several different pavements

The most expensive structural mistake on commercial ground is treating a site as a single pavement when the traffic on it is nothing of the sort.

Stalls where staff and customers leave cars are the lightest duty on any property. A stationary passenger vehicle contributes almost nothing, and those bays typically age through sunlight rather than through load. Aisles carry every vehicle that crosses the site. Service routes, apron slabs at doors, trash enclosures and every place a laden truck swings or halts carry something categorically different.

Three things happen in those places that do not happen in a parking bay. A turning axle twists the surface sideways as well as pressing on it, and a hot surface twists rather than resists. A collection vehicle sets the same concentrated load down in an identical footprint every single week. A parked trailer applies weight continuously for days, and asphalt under sustained pressure at temperature does not fully spring back.

Where a whole site was built to the stall specification, the outcome is the one facilities managers describe without prompting: immaculate parking, disintegrating service yard. Reinstating those areas in the same specification simply books the next failure. At aprons, trash pads and tight repeated turns, a rigid material usually ends the argument for good.

Working around a property that cannot close

On most commercial sites this is the variable that really sets the price, and it is the one least likely to be itemized anywhere in a bid.

A shopping center trades every day it is open. A clinic cannot be short of accessible bays for an afternoon. A warehouse cannot surrender a dock. An apartment community has residents who need a space tonight, not next week. So the job is broken into stages, and stages carry cost: repeated mobilization, repeated setup, work timed around trading hours, and somebody managing the conversation with occupiers.

The lowest number on the table is very often the one built on a staging plan the site will not tolerate. That optimism reappears later as a variation, or as an occupier who lost a trading day — and a lost trading day dwarfs whatever was shaved off the original figure.

Nail down before anyone mobilizes: the number of stages, what is out of use in each, how vehicles and people are routed around it, how accessible bays and the routes to the doors are preserved throughout, what happens to deliveries, and the criterion for letting traffic back on. That last one needs two answers, because what is ready for cars is not yet ready for a loaded truck.

Accessible bays are a legal surface, not a decorative one

Marking out a lot is the moment accessibility stops being a drawing and becomes physical, and it is the part of the work where an error has consequences beyond appearance.

Bay and aisle dimensions, how many accessible spaces a given total requires, van provision, signage, the slope of the surface and the path from the bay to the door are all governed matters rather than design preferences. Worn paint on those bays is an exposure as well as a maintenance item, because the marking is the provision — an aisle that cannot be seen is an aisle somebody parks in.

There is a quieter risk in simply repainting what is already down. A layout set decades ago and traced faithfully ever since carries whatever it originally carried, and nobody along the way has ever made a decision about it. What the requirements are is a question for the jurisdiction and for your own advisers rather than for a contractor to settle, but the moment the paint comes out is the moment to ask it, and it is the cheapest moment there will ever be.

Where we work

The metro is a single market containing several quite different pavement problems, sorted by how old the buildings are, what drives on them, what the ground does with water, and what the property has to accomplish day to day.

What the number is made of, since there is no number here

Nothing on this site carries a price, and any figure offered before someone has stood on the property is a guess. What is worth knowing is which variables the eventual figure is built from, because that is what lets you interrogate a proposal instead of just receiving one.

• Area, and how much of it is being treated as against rebuilt.
• Condition below the surface, which decides whether this is cosmetic work or structural work.
• Laid over or milled in, usually settled by whether the finished level is permitted to rise.
• Depth and duty, zone by zone, rather than one figure imposed site-wide.
• Ground and water, including whether ponding areas are being corrected or faithfully reproduced.
• Freeze exposure and elevation, which bear on both specification and calendar.
• Marking: linear footage, and how many accessible bays are involved.
• Staging: how many stages, and whether any of it has to happen overnight.
• Getting on and off the site, which on a tight property is a real line item rather than a formality.
• Waiting time before traffic returns, which is temperature-driven and constrains the schedule more than the price.

Scope, schedule and cost are the contractor’s to set once they have walked the property. What this site can do is make sure you understand what you are being quoted on.

Making two proposals answer the same question

Pavement bids resist comparison more than almost any other trade, because two competent people can stand on identical ground and reach opposite conclusions about it. One diagnoses a tired surface; the other diagnoses a failed structure. Neither is necessarily arguing in bad faith.

The fix is to fix the diagnosis first — an assessment that records what has failed and what caused it — and only then invite pricing. At that point every submission is costing the same agreed reality rather than its own author’s reading of the symptoms.

Require each submission to put the following in writing:

• The failures identified, and whether anything below the surface was examined or only what is visible.
• How much of the area is structurally gone as opposed to merely worn.
• What the water is doing, and what in this scope changes that.
• Which repairs go the full depth and which are confined to the surface.
• Whether the specification rises in the heavy-duty zones or is simply reinstated as found.
• The number of stages, and what is out of service during each.
• How accessible bays and pedestrian routes survive every stage.
• The criterion for returning traffic, stated separately for cars and for loaded vehicles.
• Whether marking is included, and whether the layout is being reconsidered or traced.
• What happens to the schedule if the season closes mid-job.

Two submissions that answer all of that can be laid side by side. A page carrying an area and a figure is an opening position rather than a scope.
